    200Nm Digital Flange Torque Sensor For Engine Transmission Test

    Ask Lasest Price
    Brand Name : SeeLong
    Model Number : SLFN-500
    Certification : CMC
    Price : USD 2939dollar
    Payment Terms : T/T
    Supply Ability : 20 pcs per month
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    200Nm Digital Flange Torque Sensor For Engine Transmission Test

    200Nm 15000rpm Digital Torque Flange For Engine and Transmission Test

    200Nm 15000rpm Digital Torque Flange For Engine and Transmission Test


    Torque sensors

    Flanged Torque Sensor adopts the machine's compact flange-flange connection design. One end of the rotor is installed in the transmission end, and the other end is directly connected with the load end, which can be easily installed in the transmission system. In addition, the sensor has a built-in speed measurement unit. Flanged torque sensors can be installed directly on the transmission equipment. The stator ring is fixed on the outer ring of the rotating rotor and supported by the stator base. Sensor volume, dimensions, materials, measurement system and signal transmission are designed specifically for harsh and complex engine test stand conditions.

    Product features

    1. 0.2% or 0.5% precision level, optional voltage or frequency signal output
    2. Realize sensor parameter identification, setting, measurement and zero balance through RS-232C interface
    3. Very small axial size
    4. Compact flange-flange connection design
    5. Digital non-contact signal transmission
    6. No bearings, no maintenance
    7. System self-check function​



    Technical parameter

    Measuring range

    0±50N.m ±100N.m ±200N.m ±500N.m ±1000N.m

    ±2000N.m ±5000N.m ±1 万 N.m

    Output signal

    5-15KHZ 0-10V 4-20mA

    Overload capacity

    120%

    Accuracy

    0.5% 0.2%

    Power supply

    24VDC

    Optimum operating Speed

    0-15000 rpm


    Response frequency


    500μs

    Insulation resistance

    >200MΩ

    Zero drift


    <0.5%

    Repetitive

    <0.1%

    Linear

    <0.1%

    Lag

    <0.1%

    Environment temperature

    -40-60℃

    Relative humidity

    <90%RH

    Temperature range

    -10-70℃

    Amplitude of transmitter

    10V

    Storage temperature range

    -25-80℃

    Transducer power consumption

    ≈4W

    Sensor current consumption

    100MA

    Sensor shell


    Strong anodized aluminum

    The response time of the strain gauge dynamic strain wave

    3.2X10-6s



    Layout
