SLFN-100 0-10000rpm 0.2%FS economical torque flange for engine
Torque sensors
Flanged torque sensor has the characteristics of simple
installation, high measuring accuracy and simple maintenance. It is
often used for measuring the torque of various power components and
has a wide range of applications.
Product features
Simple installation
High reliability and mechanical stability
Multiple outputs are available
Can be customized according to customer requirements
Compact structure
High hardness
A low moment of inertia
RPM up to 45,000 RPM
Lightweight titanium measuring body
EMC, FCC & IC certification
Minimal linear and lag errors, excellent repeatability
Technical parameter
Measuring range | 0±50N.m ±100N.m ±200N.m ±500N.m ±1000N.m ±2000N.m ±5000N.m ±1 万 N.m |
Output signal | 5-15KHZ 0-10V 4-20mA | Overload capacity | 120% |
Accuracy | 0.5% 0.2% | Power supply | 24VDC |
Optimum Operating Speed | 0-15000 rpm
| Response frequency
| 500μs |
Insulation Resistance | ＞200MΩ | Zero drift
| ＜0.5% |
Repetitive | ＜0.1% | Linear | ＜0.1% |
Lag | ＜0.1% | Environment temperature | -40-60℃ |
Relative humidity | ＜90%RH | Temperature range | -10-70℃ |
Amplitude of transmitter | 10V | Storage Temperature Range | -25-80℃ |
Transducer power consumption | ≈4W | Sensor current consumption | 100MA |
Sensor shell
| Strong anodized aluminum | The response time of the strain gauge dynamic strain wave | 3.2X10-6s |
Layout
FAQ
Q:What’s the minimum order quantity for our cooperation?
A: We support small trail order of 1 pcs for stock products.
Q: How can I learn more about the products?
A: Please leave your email and we will send you your electronic
sample book.
Q: What’s your payment term?
A: Normally 30% T/T deposit, pay in full before shipment.
Q:What’s the lead time for my orders?
A: Dynamometers production cycle is 6-8 weeks, sensors prodction
cycle is 2-3 weeks, other products please contact with us.
Q: How do we get the overall solution of the test bench?
A: Leave us your email, our technical staff will communicate with
you about the detailed plan.
Q:Can I come to visit your factory?
A: Sure, you are always welcome to have a visit.
