Product description
The main modules of this system are electric dynamometer, variable
frequency inverter system, measurement and control system, data
acquisition system and so on. At the same time, according to
different test objects and different test requirements, it will
also be equipped with power analyzer, battery simulator, chiller,
tested equipment support system, cast iron plate and shock
absorbers, protective cover and other parts.
SSCH90-4000/15000 electric dynamometer technical parameters
| Item | Electric dynamometer parameters |
| Model | SSCH90-4000/15000 |
Brand | Seelong |
| Rated Power (kW) | 90 |
Rated Torque (Nm) | 215 |
| Constant Torque Speed Range (rpm) | 0-4000 |
| Constant Power Speed Range (rpm) | 4000-15000 |
Max Working Speed (rpm) | 15000 |
Over-speed capacity | 120% |
Rated voltage (V) | AC 380 |
Rated current (A) | 169 |
Heat-dissipating method | Forced cooling |
Torque Measurement Accuracy (%FS) | 0.05/0.2/0.5 %FS |
Encoder | Shanghai Jingfen |
Model of encoder | HTL 512 |
| Can be customized |
SSCH90 electric dynamometer has the following significant
advantages:
1)Integrated design: Integrated architecture innovative design scheme, simplified
operating station.
2)Quick clamping: Simple and efficient clamping scheme is adopted to facilitate the
operation of production line staff and meet the production line
production rhythm.
3)Quick test: Through the system preset test items, can improve the efficiency
of production test.
4)Convenient operation: professional testing software, user-friendly operation interface.
5)Software features: graphical interface (Win10 operating environment), open
architecture software platform.
6)Data management: test project editing function, test report export function, test
data analysis function, user permission setting function, support
bar code entry function.
7)Strong scalability: support function customization.
Let’s become partners, we will provide lifetime free software
system upgrade for our dynamometer test bench system (Excluding the
development of new applications).
Typical application
1) Research on motor performance test and control
2) Motor efficiency evaluation
3) Feed performance evaluation of motor system
4) Motor durability assessment, etc.
Company profile
Seelong Intelligent Technology (Luoyang) Co., Ltd. is a high-tech
enterprise specializing in equipment measurement, control, design,
manufacturing, and sales services for power engineering systems in
various fields such as aerospace, automotive, and new energy; The
company is located in the beautiful peony city of Luoyang.
Seelong specializes in the research and development, production,
and service of testing equipment for new energy motors, hybrid
power systems, engines, transmissions, and more. The main products
include electric dynamometer, measurement and control system, DC
power supply, and condition guarantee system. Seelong has a
complete sales and service system, adhering to the business
philosophy of quality survival and service development, providing
users with various types of power engineering measurement and
control solutions in various fields.
Seelong's advanced design philosophy and rich industry experience
give the company a technological advantage ahead of competitors in
the same industry, and the company's products can better meet the
actual market demand. Seelong is brave in innovation. While valuing
its own technological breakthroughs and development, it has
established long-term and in-depth cooperative relationships with
multiple domestic research institutions such as Tsinghua University
and Shandong University. It has passed CE certification, ISO9001
quality system certification, AAA level enterprise certification,
obtained more than ten invention patents, and two software
copyrights. It has provided professional equipment and services to
more than a hundred users both domestically and internationally,
The enterprise has won the trust of domestic and foreign customers
with its cost-effective products and high-quality services, and has
established a long-term win-win strategic partnership.
The company always adheres to the business philosophy of "taking
technological innovation as its mission and quality service as its
purpose", constantly surpassing the advanced level in the same
industry, integrating into the world, measuring and controlling the
future, and creating high-quality products. To provide customers
with products and services with high intelligence, precision,
speed, reliability, and added value.
All employees of Seelong Intelligent Technology (Luoyang) Co., Ltd.
warmly welcome sincere cooperation from domestic and foreign
customers, and work together for the future and common development.
Company Certificates
Packaging and Shipping
FAQ
Q: What's the minimum order quantity for our cooperation?
A: We support small trail order of 1 pcs for stock products.
Q:How can I learn more about the products?
A: Please leave your email and we will send you your electronic
sample book.
Q: What's your payment term?
A: Normally 40% T/T deposit, pay in full before shipment.
Q:What's the lead time for my orders?
A: Dynamometers production cycle is 6-8 weeks, sensors production
cycle is 2-3 weeks, other products please contact with us.
Q: How do we get the overall solution of the test bench?
A: Leave us your email, our technical staff will communicate with
you about the detailed plan.
Q: Can I come to visit your factory?
A: Sure, you are always welcome to have a visit.
